Galbreath double pivot hook hoists are designed for higher hauling capacities than single pivot hook models. They allow the container to be locked during the dump cycle. Hook heights of either 54" or 61-3/4".

Features
  • Inside air controls mounted in our ergonomic power tower featuring Plug and PlayTM wiring
  • Back-up alarm & hoist up alarm with signal light in cab
  • Secondary manual controls mounted outside on driver’s side
  • Stationary rear container hold downs
  • Rear flanged rollers w/ rear transition container supports
  • Rear rollers are ductile cast iron with bronze bushing
  • T1 steel hook, fixed or adjustable hook heights
  • Roller stools with bronze bushings
  • Rear apron & bumper assembly complete w/ LED lighting
  • Steel tank with dual sight/temp gauge and air breather
  • Hoist maintenance/safety prop
  • Warranty: 2-year limited on hydraulic system
  • Customized engineering layouts ensure the best fit for each customer
Options
  • Pioneer® tarping systems
  • Pintle hooks and towing applications
  • Auxiliary hydraulic hook ups and wet kits
  • Outside rail skid plates
  • Outboard supported side rollers (standard on 75k lb. models)
  • Toolboxes
  • Fenders
  • Rear window screen protection
  • Lift axles
  • Auxiliary container stops and rear hold downs
  • Various cable ends
  • Safety and additional LED work lights
  • Speed & RPM limiting parameters
  • Scale systems
  • Backup camera systems
  • Pumps and PTO's
Models
U20-DPHK-120

SINGLE AXLE DUAL PIVOT HOOK HOIST 20K Capacity on 120 MODELS - Fixed 54" Hook Height

U20-DPHK-144

SINGLE AXLE DUAL PIVOT HOOK HOIST 20K Capacity on 144 MODELS - Fixed 54" Hook Height

U30-DPHK-176

SINGLE AXLE DUAL PIVOT HOOK HOIST 30K Capacity on 176 MODELS - Fixed 54" Hook Height

U3-DPHK-160

TANDEM AXLE DUAL PIVOT HOOK HOIST 30K Capacity on 160 MODELS - Fixed 54" Hook Height

U4/5-DPHK-176

TANDEM AXLE DUAL PIVOT HOOK HOIST 40K Capacity on 176 MODELS - Adj. 54" or 62" Hook Height

U4/5-DPHK-200

TANDEM AXLE DUAL PIVOT HOOK HOIST 40K Capacity on 200 MODELS - Adj. 54" or 62" Hook Height

U5-DPHK-176

TANDEM AXLE DUAL PIVOT HOOK HOIST 50K Capacity on 176 MODELS - Fixed 62" Hook Height

U5-DPHK-200

TANDEM AXLE DUAL PIVOT HOOK HOIST 50K Capacity on 200 MODELS - Fixed 62" Hook Height

U5-DPHK-224

TANDEM AXLE DUAL PIVOT HOOK HOIST 50K Capacity on 224 MODELS - Fixed 62" Hook Height

U6-DPHK-176

TANDEM AXLE DUAL PIVOT HOOK HOIST 60K Capacity on 176 MODELS - Fixed 62" Hook Height

U6-DPHK-200

TANDEM AXLE DUAL PIVOT HOOK HOIST 60K Capacity on 200 MODELS - Fixed 62" Hook Height

U6-DPHK-224

TANDEM AXLE DUAL PIVOT HOOK HOIST 60K Capacity on 224 MODELS - Fixed 62" Hook Height

Applications

Designed so the hoist operates like a dump truck when emptying loaded containers. Primarily used in the Waste and Recycling industries but more and more companies are looking to the Dual Pivot Hooks as their replacement to their current fleet of dump trucks as Hook Hoist can perform more than one type task by just swapping out the container type needed for the job.
